Gun Barrel Antenna
The gun barrel antenna is a type of omnidirectional antenna that is designed to be installed outside of a building to improve the strength and range of signal. It is a popular solution for individuals and businesses that require reliable and consistent WiFi coverage over a large area.
Installation Method

Step 1: Find a position where could receive great signal,mostly a higher position, like at rooftop. Install outdoor antenna at it and make it toward the base station.
Note: the outdoor antenna shall receive good signal, otherwise the repeater could not work.
Step 2: Connect outdoor antenna to booster at BTS connector with the cable.
Step 3: Connect indoor antenna to booster at MS connector. And it would be better to install it at a height of 2 meters.
Note: The two antennas shall be totally separated by a brick wall with a distance of at least 10 meters. Otherwise, the signal would intervene to each other, showing full
of signal on display, but actually the booster doesn’t work properly.
Step4: Plug in power supply and done!

Product Introduction

Products Feature

Omnidirectional
360° complete signal reception omnidirectional.This Omnidirectional nature helps to increase the range and strength of the signal.

Product Feature (1)
Product Feature (2)


High Gain

Another characteristic of this outdoor antennas is the high gain, which refers to the ability of the antenna to amplify the signal. The higher the gain of an antenna, the stronger the signal will be. The higher the gain of an antenna, the more focused the energy is, which allows for longer-range communication.

Premium Materials &Outdoor Weather Resistance
Durable PVC material to achieve better signal reliability under all kinds of inclement weather antisunburn, waterproof, dampproof,anti-freezing, windproof,etc

Product Feature (3)

Application

The gun barrel antenna is commonly used in applications where reliable and consistent coverage is required over a large area. Gun barrel antennas can be installed on the roof of a building or on a pole to improve the strength and range of the signal.

Another application of gun barrel antennas is in large commercial and industrial buildings. These buildings often have thick walls and other obstacles that can interfere with the signal. An gun barrel antenna can be installed to boost the signal strength and overcome these obstacles.

Product Applicationc

Communication Base Station
Roof

Product Name

Gun Barrel Antenna

Frequency Range

700-2700MHz

Impendence

50Ω

V.S.W.R

≤2

Gain (dBi)

12dBi, 18dBi, Customized

Polarization Type

Vertical Polarization

Max Power

100

Operating Temperature

-40℃~+85℃

Cable Type

RG174, RG58, Customized

Antenna Connector

CRC9, N Type, SMA, TS9, Customized

Installation Method

Bracket Installation

Cable Length

1m, 3m, 5m, Customized

Antenna Size

42*6.3cm, 23*6.5cm, Customized

Radiation

Omnidirectional
