5G 5dBi Swivel Rubber Antenna with SMA Male Connector
Introduction:
The 5g 5dbi swivel rubber antenna is designed for high-performance wireless communication in 5g routers, cpe devices, gateways, and other rf applications. Operating at the 3700~4200 mhz frequency range, this antenna provides stable signal transmission and enhanced connectivity for modern 5g networks.
Featuring 5dbi gain, vertical polarization, and an omni-directional radiation pattern, this swivel rubber antenna ensures wide and consistent signal coverage. The sma male connector allows quick installation and compatibility with various wireless devices. With 50 ohm impedance, ≤1.92 vswr, 50w maximum input power, and a temperature range of -20°c to 70°c, it delivers reliable rf performance in demanding environments.
Key Features
- 3700~4200 mhz frequency range for 5g communication applications
- 5dbi gain for improved wireless signal strength and coverage
- Omni-directional radiation pattern for stable signal distribution
- Sma male connector for easy installation and connection
- Swivel design for flexible antenna positioning
- -20°c to 70°c operating temperature for reliable performance
General Information:
| Product No.: | YC-EX20009 | |
| Connector Series: | Rubber Duck Antennas | |
| Brand: | Metabee | |
| Connector Type: | SMA Male | |
| Antenna Orientation: | Swivel or Foldable | |
| Dimensions: | Customized | |
| Color: | Black | |
| Operating Temperature: | -20℃ to +70℃ | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 3700~4200 MHz | |
| Gain: | 5dBi | |
| VSWR: | ≤1.92 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omnidirectional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
Rubber Duck Antenna Test
Factory Equipments
Applications of this 5G 5dBi Swivel Rubber Antenna:
Rubber Duck Antennas are compact, flexible, and typically omnidirectional antennas widely used in wireless communication devices where space, portability, and reliable signal coverage are important.
Here are some key applications:
- Two-Way Radios and Walkie-Talkies
- WiFi Routers and Wireless Access Points
- IoT (Internet of Things) Devices
- Cellular Communication Equipment
- GPS and GNSS Tracking Devices
- Wireless Security Systems
- Industrial Automation and Control Systems
- Drone and Remote Control Systems
- Smart Home Devices
- Marine and Outdoor Communication Equipment
