3V3 High Power D-Sub Male Right Angle Connector, PCB Mount, Through Hole
Introduction:
This is a right angle 3V3 D-sub connector with an A-size shell. Designed for multi-channel, high-frequency signal transmission, it integrates three high-performance power contacts. Its 90-degree angle allows for parallel mounting to the PCB, significantly conserving space within the device and making it ideal for compact layouts. The connector utilizes a through-hole mounting method for secure soldering to the PCB, ensuring mechanical stability of the connection. Precision-turned, gold-plated contacts ensure excellent signal integrity and long-term reliability. Our complete D-sub product line and dedicated accessories enable us to provide flexible and cost-effective connectivity solutions to meet any complex application challenge.
This 3V3 D-sub right angle connector has many great features, including:
- Right-Angle Design: Saves critical vertical space, optimizing compact layouts.
- Secure PCB Mounting: Through-hole design creates a robust mechanical and electrical bond, resisting vibration.
- Precision Machined Contacts: Gold-plated brass contacts offer superior conductivity and long-term corrosion resistance.
- 4-40 UNC Screw Lock: Locks the mating connector in place, preventing disconnections from vibration or pull.
- Wide Operating Temperature: Reliable performance in extreme conditions, from -55°C to +125°C.
- Metal Shielding Shell: Provides excellent EMI shielding and robust protection against shock and vibration.
Main Specifications:
General Information:
| Product Number: | YC-681-5507 | |
| Connector Series: | Combo D-Sub | |
| Contact Arrangement: | 3V3 | |
| Orientation: | Right Angle | |
| Connector Gender: | Male | |
| Number of Contacts: | 3 Pin | |
| Number of Rows: | 1 | |
| Shell Sizes: | A | |
| Mount Type: | PCB Mount | |
| Mount Feature: | Through Hole | |
| Contact Termination: | Solder | |
| Contact Type: | Machined Contact | |
| Contact Function: | Power |
Materials and Plating:
| Shell Material: | Steel | |
| Shell Plating: | Nickel Plating | |
| Contact Material: | Brass | |
| Contact Plating: | Gold Plating | |
| Contact Plating Thickness: | 3.00µin（0.076µm） | |
| Insulator Material: | Thermoplastic Polyester |
Electrical Performance:
|
High power contacts current rating: |
40A | |
| Rated Voltage: | 250V AC |
Environmental Performance:
| Temperature Range: | -55℃ to +125℃ | |
| IP Rating: | Not Applicable | |
| Flammability Rating: | UL94 V-0 |
Applications of the 3V3 D-sub right angle connector:
- Mobile Robotics and AGV;
- Professional A/V and Stage Lighting;
- Medical Equipment Carts;
- Industrial Power Supplies and DC Motor Drives;
- Industrial Lasers and Plasma Cutting Systems;
- High-Power Test and Measurement.
Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
