2.4 GHz 5dBi Swivel WiFi Rubber Duck Antenna with SMA Male
Introduction:
5.4 GHz 5dBi swivel WiFi rubber duck antenna is a high-performance wireless antenna designed for 2.4 GHz WiFi applications requiring stable and extended signal coverage. With a 5dBi gain and omnidirectional radiation pattern, this rubber duck antenna provides reliable signal transmission and reception in multiple directions, making it suitable for routers, wireless modules, IoT devices, and other communication systems.
Featuring vertical polarization, 50 Ohm impedance, and a maximum input power of 50W, this antenna ensures efficient RF performance and excellent compatibility with various wireless devices. The SMA male connector enables quick installation, while the swivel design allows flexible angle adjustment to achieve optimized signal positioning in different environments.
With a VSWR of ≤1.92 and an operating temperature range of -20 °C to 70 °C, this WiFi rubber duck antenna delivers consistent performance and durability for indoor and industrial wireless applications.
Key Features
- 2.4 GHz frequency range for WiFi communication
- 5dBi gain for enhanced wireless coverage
- Omnidirectional radiation pattern for wide signal distribution
- Swivel design for flexible installation adjustment
- SMA male connector with 50 Ohm impedance
- Supports 50W power input and -20 °C to 70 °C operation
General Information:
| Product No.: | YC-EX20006 | |
| Connector Series: | Rubber Duck Antennas | |
| Brand: | Metabee | |
| Connector Type: | SMA Male | |
| Antenna Orientation: | Foldable or Swivel | |
| Dimensions: | Customized | |
| Color: | Black | |
| Operating Temperature: | -20℃ to +70℃ | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 2.4 GHz | |
| Gain: | 5dBi | |
| VSWR: | ≤1.92 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omnidirectional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
Rubber Duck Antenna Test
Factory Equipments
Applications of this 2.4 GHz 5dBi Swivel WiFi Rubber Duck Antenna:
Rubber Duck Antennas are compact, flexible, and typically omnidirectional antennas widely used in wireless communication devices where space, portability, and reliable signal coverage are important.
Here are some key applications:
- Two-Way Radios and Walkie-Talkies
- WiFi Routers and Wireless Access Points
- IoT (Internet of Things) Devices
- Cellular Communication Equipment
- GPS and GNSS Tracking Devices
- Wireless Security Systems
- Industrial Automation and Control Systems
- Drone and Remote Control Systems
- Smart Home Devices
- Marine and Outdoor Communication Equipment
Factory pricing and exceptional product quality. Get a free quote now!
