2.4 GHz 3dBi Short Rubber WiFi Antenna, SMA Male
Introduction:
Optimize your wireless connectivity with the 2.4 GHz 3dBi short rubber WiFi antenna, equipped with an SMA male connector. This compact antenna is meticulously engineered to provide reliable signal reception and transmission for a variety of 2.4 GHz wireless devices. Its discreet profile makes it an ideal solution for applications where space is at a premium, ensuring stable performance without obtrusive sizing. From improving home network signals to enhancing industrial IoT deployments, this antenna delivers essential wireless performance.
Boasting a 3dBi gain, this antenna effectively extends the range and improves the stability of your wireless network. The low voltage standing wave ratio (VSWR) of ≤1.92 guarantees efficient power transfer and minimal signal loss, maximizing the antenna’s operational effectiveness. Designed for vertical polarization and maintaining a standard 50 Ohm impedance, it seamlessly integrates with conventional wireless systems. It is built to endure, operating flawlessly across a broad temperature spectrum from -20 °C to 70 °C, and capable of handling a maximum input power of 50W. The SMA male connector ensures secure and straightforward installation across compatible devices. This antenna represents a pragmatic upgrade for any system requiring consistent and enhanced 2.4 GHz wireless functionality.
Key Features
- Compact Design: Its short, rubberized form factor allows for discreet and convenient placement.
- Reliable Gain: The 3dBi gain provides a dependable boost to 2.4 GHz wireless signals.
- Efficient Operation: An impressively low VSWR of ≤1.92 ensures maximum power transfer and minimal signal loss.
- Broad Compatibility: Features a standard SMA male connector for widespread device integration.
- Durable Performance: Engineered to function reliably in temperatures ranging from -20 °C to 70 °C.
- Standard Polarization: Utilizes vertical polarization for consistent and effective signal transmission.
General Information:
| Product No.: | YC-EX20035 | |
| Connector Series: | Rubber Duck Antennas | |
| Brand: | Metabee | |
| Connector Type: | SMA Male | |
| Antenna Orientation: | Straight | |
| Dimensions: | Customized | |
| Color: | Black | |
| Operating Temperature: | -20℃ to +70℃ | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 2.4 GHz | |
| Gain: | 3dBi | |
| VSWR: | ≤1.92 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omnidirectional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
Rubber Duck Antenna Test
Factory Equipments
Applications of this 2.4 GHz 3dBi Short Rubber WiFi Antenna:
Rubber Duck Antennas are compact, flexible, and typically omnidirectional antennas widely used in wireless communication devices where space, portability, and reliable signal coverage are important.
Here are some key applications:
- Two-Way Radios and Walkie-Talkies
- WiFi Routers and Wireless Access Points
- IoT (Internet of Things) Devices
- Cellular Communication Equipment
- GPS and GNSS Tracking Devices
- Wireless Security Systems
- Industrial Automation and Control Systems
- Drone and Remote Control Systems
- Smart Home Devices
- Marine and Outdoor Communication Equipment
